The independent swing controls for each channel are also a really nice touch, adding functionality to older devices without built-in swing. Parameters for each of the channels can be stored and recalled as presets, while individual timing offsets of up to 300ms per channel, either positive or negative, should be more than enough to compensate for timing discrepancies between pieces of hardware.
Channel 1 also has its own dedicated TRS output alongside the DIN socket, which can transmit the analogue clock signal or be used to generate analogue LFO signals for feeding to CV-equipped synths.Ī lot of thought has clearly gone into the design of the Multiclock.
Each channel can generate MIDI clock, DIN sync or analogue clock (although the latter requires a breakout cable on channels 2 to 4). Once you’ve decided on a clock source, the main strength of the Multiclock is its versatility this is far more than just a simple clock generator with four outputs.
#ERM MULTICLOCK ERR MANUAL#
It’s worth noting that E-RM explicitly state that this is the recommended approach, going so far as to point out in the manual that the Multiclock “is not built to be synchronised by a master DAW using MIDI or USB MIDI”. If you’re working at 48 kHz, that equates to jitter “as low as ☐.2 µs”, which although not as accurate as E-RM’s own internal clock (with average jitter of 0.1 µs), is still significantly more accurate than most DAWs and hardware sequencers.
#ERM MULTICLOCK ERR SOFTWARE#
The plugin sits on an instrument track in your chosen software host and generates a sync signal, which can be routed to one of your interface’s audio outputs, then connected to the Multiclock’s 1/4-inch input. It’s the latter approach that E-RM are keen to stress as one of the main selling points of the device, because the unit can derive its clock signal via the Multiclock Audio Sync plugin (Mac/Windows VST or Mac AU) for sample-accurate synchronisation with your DAW.
#ERM MULTICLOCK ERR GENERATOR#
The Multiclock can generate its own clock signal using the same ultra-stable clock generator found in the Midiclock (which E-RM claim is 50,000 times more accurate than the average DAW) or sync to an external clock signal. E-RM’s newly released follow-up is the Multiclock, a much more advanced product, which acts as a multi-format sync box capable of outputting up to four channels of MIDI, DIN or analogue clock to synchronise hardware such as drum machines, sequencers and synth arpeggiators via a rock-solid clock signal. It might be basic, but it does its job incredibly effectively and we’ve already seen it sitting in a few studio setups and live rigs. I found that the Berlin-based company’s debut product was a very simple device, which generates a single channel of rock-solid MIDI clock to feed into your hardware. When I reviewed E-RM’s Midiclock last year, I was hugely impressed. Greg Scarth checks out their new Multiclock, which offers sample-accurate DAW synchronisation and the versatility to handle everything from modern MIDI gear to vintage analogue kit and modular synths.
#ERM MULTICLOCK ERR PRO#
Turnlab is a company based in the centre of Antwerp (Belgium) specialised in pro audio equipment & instruments.E-RM specialise in improving the timing of your equipment.
It allows you to route and merge other MIDI data from four USB MIDI ports and the onboard MIDI In with the accurate clock signals.
To become the central connection hub of your setup, a powerful MIDI Router is available. If you then have found the sweet spot, you can add a bit of shuffle. To compensate for any time lag of your connected gear, you can shift each of the four output channels individually and in realtime back and forth relative to the master clock. Analogue clock signals are configurable in polarity and start/reset behavior and individual clock dividers are available. Each channel can be set to either emit MIDI, DIN sync or analogue clock. Synchronisation of the multiclock to a DAW relies on a sample accurate audio clock, which allows for rock solid sync signals. The multiclock can be it’s own master or synced to external MIDI, DIN sync or Analogue master clocks.
